E300-9D


1. 英特尔®至强®处理器 D-2123IT,4 核,8 线程,
60W
2. 片上系统3. 1 个内置 2.5“ 驱动器托架4. 高达 512GB ECC RDIMM,
高达 256GB ECC RDIMM
DDR4-2400Mz;在 4 个内存插槽中
5. 1 个板载 OCuLink 端口(或 1 个 PCI-E 3.0 x4 NVMe),1 个 PCI-E 3.0
x8 (LP) 开放插槽
6. 2 个 10GBase-T 局域网和 1 个用于 IPMI 2.0 的专用
局域网
7. 1 个 VGA、2 个 USB 3.0、1 个 TPM 2.0 接头8. 3x 40x28mm 4针PWM风扇9. 150W可锁定直流电源适配器image.png

Product SKUs

SYS-E300-9D
  • SuperServer E300-9D (Black)



Motherboard


Super X11SDV-4C-TLN2F


Processor/Cache

CPU
  • Intel® Xeon® processor D-2123IT,
    CPU TDP support 60W

Cores / Cache
  • 4 Cores, 8 Threads



System Memory

Memory Capacity
  • Up to 512GB DDR4 ECC LRDIMM

  • Up to 256GB DDR4 ECC RDIMM

  • 4 DIMM slots

Memory Type
  • 2666/2400/2133MHz ECC DDR4 ECC LRDIMM and ECC RDIMM

  • Operating speed up to 2400MHz

DIMM Sizes
  • RDIMM: 4GB, 8GB, 16GB, 32GB, 64GB

  • LRDIMM: 16GB, 32GB, 64GB, 128GB

Memory Voltage
  • 1.2 V

Error Detection
  • Corrects single-bit errors

  • Detects double-bit errors
      (using ECC memory)



On-Board Devices

Chipset
  • System on Chip

SATA
  • SoC controller for 4 SATA3 (6Gbps) ports; RAID 0,1,5,10 RSTe

Network Controllers
  • Dual 10GBase-T LAN, SoC

IPMI
  • Support for Intelligent Platform Management Interface v.2.0

  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Graphics
  • Aspeed AST2500 BMC



Input / Output

SATA
  • 1 SATA3 (6Gbps) port (SATA/SAS HDD/SSD)

LAN
  • 2 10GBase-T LAN ports

  • 1 Dedicated IPMI LAN port

USB
  • 2 USB 3.0 ports (rear)

Display
  • 1 VGA port

TPM
  • 1 TPM 2.0 header


Chassis

Form Factor
  • Compact

Model


Dimensions

Width
  • 10" (254mm) / 15" (381mm) - pkg.

Height
  • 1.7" (43mm) / 10.87" (276mm) - pkg.

Depth
  • 8.9" (226mm) / 5.59" (142mm) - pkg.

Weight
  • Gross Weight: 7.5 lbs (3.4 kg)

  • Net Weight: 3.45 lbs (1.56 kg)

Available Colors
  • Black



Front Panel

Buttons
  • Power On/Off button

LEDs
  • Power LED (Hard drive activity LED)



Expansion Slots

PCI-Express
  • 1 onboard OCuLink port (or 1 PCI-E 3.0 x4 NVMe)

  • 1 PCI-E 3.0 x8 (LP) open slot



Drive Bays

Internal
  • 1 Internal 2.5" drive bay



System Cooling

Fans
  • 3x 40x28mm 4-PIN PWM Fan



Power Supply

150W Lockable DC power adapter (adapter cannot be mounted by the kit)


System BIOS

BIOS Type
  • 128Mb SPI Flash with AMI BIOS

BIOS Features
  • PCI 3.0

  • ACPI 5.0

  • USB Keyboard support

  • Hardware BIOS Virus protection

  • SMBIOS 2.8

  • UEFI 2.4

  • RTC (Real Time Clock) Wakeup



Management

Software
  • Intel® Node Manager

  • IPMI 2.0

  • KVM with dedicated LAN

  • NMI

  • SUM

  • SuperDoctor® 5

  • Watch Dog

Power Configurations
  • ACPI Power Management

  • +12V DC Power Input

  • Control of power-on for recovery from AC power loss

  • CPU thermal trip support for processor protection

  • M.2 NGFF connector, Node Manager Support, SDDC, System level control, UID, WOL

Fan
  • Fans with tachometer status monitoring

  • Status monitor for speed control

  • Low noise fan speed control

  • Pulse Width Modulated (PWM) fan connectors




Operating Environment / Compliance


RoHS
  • RoHS Compliant


Environmental Spec.
  • Operating Temperature:
       0°C to 40°C (32°F to 104°F)

  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)

  • Operating Relative Humidity:
       8% to 90% (non-condensing)

  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
