超微主板X12DSC-A6

图片关键词

Key Features

3rd Gen Intel? Xeon? Scalable processors
Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Intel? C621A
Up to 4TB RDIMM, DDR4-3200MHz; Up to 4TB LRDIMM, DDR4-3200MHz, DDR4-3200MHz
Up to 2TB Intel? Optane? Persistent Memory 200 Series, DDR4-3200MHz, in 16 DIMM slots
3 PCI-E 4.0 x16
M.2 Form Factor: 22110
AIOM slot

Product SKUs

MBD-X12DSC-A6	X12DSC-A6



Physical Stats

Form Factor	Proprietary
Dimension	14.8" x 10.9" (37.59cm x 27.69cm)



Processor

CPU	3rd Gen Intel? Xeon? Scalable processors Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Core	Up to 40 cores



System Memory

Memory Capacity	16 DIMM slots Up to 2TB Intel? Optane? Persistent Memory 200 Series, DDR4-3200MHz Up to 4TB ECC LRDIMM, DDR4-3200MHz; Up to 4TB ECC RDIMM, DDR4-3200MHz
Memory Type	3200/2933/2666MHz ECC DDR4 LRDIMM, RDIMM
DIMM Sizes	16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage	1.2V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)



On-Board Devices

Chipset	Intel? C621A
SATA	Intel? C621A controller for 4 SATA3 ports; RAID 0,1,5,10
Network Controllers	N/A

Expansion Slots

0

0
