超微主板X11SWN-H-WOHS

超微主板X11SWN-H-WOHS

图片关键词‘’

Key Features

  1. Intel? 8th Generation Core? i7-8665UE Processor

  2. Dual Channel DDR4 2400MHz SO-DIMM, up to 64GB

  3. Small form factor with rich I/O: 2 GbE, 8 USB and 6 COM

  4. Intel UHD Graphics 620 with 4K and 24 EU for Vision Solution

  5. 3 display support(DP++, HDMI and 48-bit LVDS)

  6. Rich expansion: 3 x M.2 (B/E/M key) for NVMe/SATA/Wifi/BT/LTE

  7. 12-24V wide range power input with RVP and TVS

  8. Without heatsink for customer's flexible thermal design


Product SKUs

MBD-X11SWN-H-WOHS

  • X11SWN-H-WOHS



Physical Stats

Form Factor

  • 3.5" SBC

Dimension

  • 5.7" x 4" (14.6cm x 10.16cm)



Processor

CPU

  • 8th Generation Intel? Core? i7-8665UE Processor

  • Single Socket FCBGA-1528 supported, CPU TDP supports Up to 15W TDP

Core

  • Up to 4 cores, 8 threads / 8MB Cache



System Memory

Memory Capacity

  • 2 DIMM slots

  • Up to 64GB SODIMM, DDR4-2400MHz

Memory Type

  • 2666/2400/2133MHzDDR4 2400MHz 260pin SODIMM

DIMM Sizes

  • 4GB, 8GB, 16GB, 32GB

Memory Voltage

  • 1.2V



On-Board Devices

Chipset

  • System on Chip

Audio

  • ALC 888S HD Audio

Graphics

  • Intel? UHD Graphics 620

  • Dual channel 48-bit LVDS(max. resolution up to 1920x1200@60Hz), _x005f HDMI 1.4 (max. resolution up to 4096x2160@30Hz), DP++ (max. resolution up to 4096x2304@60Hz)

Network Controllers

  • Single LAN with Intel? PHY I219LM LAN controller

  • Single LAN with Intel? Ethernet Controller I210IT

SATA
