超微主板E300-9D

超微主板E300-9D


1. 英特尔?至强?处理器 D-2123IT，4 核，8 线程，
60W2. 片上系统3. 1 个内置 2.5“ 驱动器托架4. 高达 512GB ECC RDIMM，
高达 256GB ECC RDIMM
DDR4-2400Mz;在 4 个内存插槽中5. 1 个板载 OCuLink 端口（或 1 个 PCI-E 3.0 x4 NVMe），1 个 PCI-E 3.0
x8 （LP） 开放插槽6. 2 个 10GBase-T 局域网和 1 个用于 IPMI 2.0 的专用
局域网7. 1 个 VGA、2 个 USB 3.0、1 个 TPM 2.0 接头8. 3x 40x28mm 4针PWM风扇9. 150W可锁定直流电源适配器image.png

Product SKUs

SYS-E300-9D

  • SuperServer E300-9D (Black)



Motherboard


Super X11SDV-4C-TLN2F


Processor/Cache

CPU

  • Intel? Xeon? processor D-2123IT,
    CPU TDP support 60W

Cores / Cache

  • 4 Cores, 8 Threads



System Memory

Memory Capacity

  • Up to 512GB DDR4 ECC LRDIMM

  • Up to 256GB DDR4 ECC RDIMM

  • 4 DIMM slots

Memory Type

  • 2666/2400/2133MHz ECC DDR4 ECC LRDIMM and ECC RDIMM

  • Operating speed up to 2400MHz

DIMM Sizes

  • RDIMM: 4GB, 8GB, 16GB, 32GB, 64GB

  • LRDIMM: 16GB, 32GB, 64GB, 128GB

Memory Voltage

  • 1.2 V

Error Detection

  • Corrects single-bit errors

  • Detects double-bit errors
      (using ECC memory)



On-Board Devices

Chipset

  • System on Chip

SATA

  • SoC controller for 4 SATA3 (6Gbps) ports; RAID 0,1,5,10 RSTe

Network Controllers

  • Dual 10GBase-T LAN, SoC

IPMI

  • Support for Intelligent Platform Management Interface v.2.0

  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Graphics

  • Aspeed AST2500 BMC



Input / Output

SATA

  • 1 SATA3 (6Gbps) port (SATA/SAS HDD/SSD)
