超微主板 X12SPG-NF 支持第三代至强 LGA4189

超微主板 X12SPG-NF 支持第三代至强 LGA4189


Key Features

  1. 3rd Gen Intel? Xeon? Scalable processors, Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP

  2. Intel? C621A


    • Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz

    • Up to 2TB Intel? Optane? Persistent Memory 200 Series, in 8 DIMM slots


    • 3 PCIe 4.0 x16 Proprietary Slots

    • 2 PCIe 4.0 NVMe x4

    • M.2 Interface: 2 SATA/PCIe 3.0 x4

    • M.2 Form Factor: 2280/22110

    • M.2 Key: M-Key

    • 1 PCIe 4.0 x8 AIOM



    • Single LAN with Realtek RTL8211F PHY

    • (dedicated IPMI)


    • Intel? C621A controller for 2 SATA3 (6

    • Gbps) ports; RAID 0,1

Product SKUs
MBD-X12SPG-NF
Physical Stats
Form Factor

  • Proprietary

Dimension

  • 9.6" x 14.5" (24.38cm x 36.83cm)

Processor
CPU

  • 3rd Gen Intel? Xeon? Scalable processors

  • Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP

Core

  • Up to 40 cores

System Memory
Memory Capacity

  • 8 DIMM slots

  • Up to 2TB Intel? Optane? Persistent Memory 200 Series

  • Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz; Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz

Memory Type

  • 3200/2933/2666 MT/s ECC , DDR4 LRDIMM (3DS), RDIMM (3DS)

DIMM Sizes

  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB

  • LRDIMM: 64GB, 128GB

  • RDIMM: 8GB, 16GB, 32GB, 64GB

Memory Voltage

  • 1.2V

Error Detection

  • Corrects single-bit errors

On-Board Devices
Chipset

  • Intel? C621A

SATA

  • Intel? C621A controller for 2 SATA3 (6 Gbps) ports; RAID 0,1
