超微主板 X12DGU 支持第三代至强 LGA4189

超微主板 X12DGU 支持第三代至强 LGA4189


Key Features


    • 3rd Gen Intel? Xeon? Scalable processors

    • Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s

  2. Intel? C621A


    • Up to 8TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 8TB 3DS ECC LRDIMM, DDR4-3200MHz

    • Up to 8GB Unbufferred ECC Intel? Optane? Persistent Memory 200 Series, DDR4-3200MHz, in 32 DIMM slots


    • 25 PCIe 4.0 x8

    • M.2 Interface: 1 PCIe 4.0 x4

    • M.2 Form Factor: 2280/22110

    • 1  PCIe 4.0 x16

  5. Dual LAN with 2x 10Gbase-T with Intel ? Ethernet Controller X710

  6. 1 VGA port

Product SKUs
MBD-X12DGU
Physical Stats
Form Factor

  • Proprietary

Dimension

  • 14.29" x 10.9" (17.32cm x 27.69cm)

Processor
CPU

  • 3rd Gen Intel? Xeon? Scalable processors

  • Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s

Core

  • Up to 40 cores

System Memory
Memory Capacity

  • 32 DIMM slots

  • Up to 8GB Unbuffered Intel? Optane? Persistent Memory 200 Series, DDR4-3200MHz

  • Up to 8TB 3DS ECC LRDIMM, DDR4-3200MHz; Up to 8TB 3DS ECC RDIMM, DDR4-3200MHz

  • Up to 8TB Intel? Optane? Persistent Memory in memory mode.

Memory Type

  • 3200/2933/2666 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)

DIMM Sizes

  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB

Memory Voltage

  • 1.2V

Error Detection

  • Corrects single-bit errors

  • Detects double-bit errors (using ECC memory)

On-Board Devices
Chipset

  • Intel? C621A

SATA

  • Intel? C621A controller for 12 SATA3 (6 Gbps) ports; RAID 0,1,5,10

IPMI 0
0
