超微准系统 SYS-420GP-TNAR

超微准系统 SYS-420GP-TNAR

Key Features

Dual Socket P+ (LGA-4189) 3rd Gen Intel? Xeon Scalable Processors
Intel? C621A Chipset

32 DIMM Slots;
Up to 8TB DRAM;
Up to 8TB Intel? Optane Persistent Memory (up to 12TB with DRAM);
3200/2933/2666 ECC DDR4 LRDIMM;RDIMM;
Intel Optane Persistent Memory 200 series

10 PCIe Gen 4.0 X16 LP Slots
AIOM/OCP 3.0 Support

Flexible networking options

2 M.2 NVMe and SATA for boot drive only
6x 2.5" Hot-swap NVMe/SATA/SAS drive bays

4 heavy duty fans with optimal fan speed control
4x 2200W redundant Titanium level power supplies

Product SKUs
SuperServer SYS-420GP-TNAR (Black Front & Silver Body)

Motherboard
Super X12DGO-6

Processor
CPU	Dual Socket P+ (LGA-4189) 3rd Gen Intel Xeon? Scalable processors Support CPU TDP 270W
Cores	Up to 40C/80T; Up to 60MB Cache

GPU
Supported GPU	HGX A100 8-GPU SXM4 Multi-GPU Board
CPU-GPU Interconnect	PCIe 4.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect	NVIDIA? NVLink? with NVSwitch?
Certification

System Memory
Memory	Memory Capacity: 32 DIMM slots Up to 8TB: 32x 256 GB DRAM Up to 12TB: 16x 512 GB PMem Memory Type: 3200/2933/2666MHz ECC DDR4 RDIMM/LRDIMM Intel? Optane? persistent memory 200 series
Memory Voltage	1.2 V
Error Detection	ECC

On-Board Devices
SATA	SATA3 (6Gbps); RAID 0/1/5/10 support
Chipset	Intel? C621A
Network Connectivity	2x 10GbE BaseT with Intel? X550-AT2 (optional)
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Input / Output
Video	1 VGA port(s)
