超微主板 X11SCZ-Q 支持LGA1151 针脚规格

超微主板 X11SCZ-Q 支持LGA1151 针脚规格


Key Features

  1. 8th/9th Generation Intel? Core? i9/Core? i7/Core?i5/Core?i3/Pentium?/Celeron? Processor.
    Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP

  2. Intel? Q370

  3. Single LAN with Intel? Ethernet Controller I210-AT
    Single LAN with Intel? PHY I219LM LAN controller

  4. Up to 128GB Unbuffered non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

  5. 1 PCIe 3.0 x16,
    2 PCIe 3.0 x4 (in x8 slot)
    M.2 Interface: 1 SATA/PCIe 3.0 x4
    M.2 Form Factor: 2280/22110
    M.2 Key: M-Key

  6. Intel? Q370 controller for 5 SATA3 (6 Gbps) ports; RAID 0,1,5,10

  7. 1 DVI - I port, 2 DP (DisplayPort) ports,
    3 Independent Displays

Product SKUs
MBD-X11SCZ-Q
Physical Stats
Form Factor

  • uATX

Dimension

  • 9.6" x 9.6" (24.38cm x 24.38cm)

Processor
CPU

  • 8th/9th Generation Intel? Core? i9/Core? i7/Core? i5/Core? i3/Pentium?/Celeron? Processor

  • Single Socket LGA-1151 (Socket H4) supported, CPU TDP supports Up to 95W TDP

System Memory
Memory Capacity

  • 4 DIMM slots

  • Up to 128GB Unbuffered non-ECC UDIMM, DDR4-2666MHz

Memory Type

  • 2666/2400/2133/1866/1600 MT/s SDRAM 72-bit, 288-pin

DIMM Sizes

  • 4GB, 8GB, 16GB, 32GB

Memory Voltage

  • 1.2V

On-Board Devices
Chipset

  • Intel? Q370

SATA

  • Intel? Q370 controller for 5 SATA3 (6 Gbps) ports; RAID 0,1,5,10

Audio

  • ALC 888S HD Audio

Graphics

  • 1 Intel? HD Graphics port(s)

Network Controllers

  • Single LAN with Intel? PHY I219LM LAN controller

  • Single LAN with Intel? Ethernet Controller I210-AT

Input / Output
LAN

  • 2 RJ45 Gigabit Ethernet LAN ports

USB

  • 6 USB 3.1 Gen2 port(s) (2 via header; 1 rear type C; 3 rear type A)

  • 7 USB 2.0 port(s) (6 via header; 1 Type A)

  • 2 USB 3.1 Gen1 port(s) (2 via header)
