超微主板 X12DHM-6 支持志强第三代LGA4189

超微主板 X12DHM-6 支持志强第三代LGA4189

Key Features

3rd Gen Intel? Xeon? Scalable processors
Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s

Intel? C621A

Up to 8TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 8TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 8TB Intel? Optane? Persistent Memory, DDR4-3200MHz, in 32 DIMM slots

5 PCIe 4.0 x16,
8 PCIe 4.0 NVMe x4
M.2 Interface: 2 SATA/PCIe 3.0 x2, RAID 0 & 1
M.2 Form Factor: 2280/22110
1 PCIe 4.0 x16, AIOM (OCP3.0 Compliant)

Intel? C621A controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
1 VGA D-Sub Connector port

Product SKUs
MBD-X12DHM-6

Physical Stats
Form Factor	Proprietary
Dimension	17" x 10.7" (43.18cm x 27.18cm)

Processor
CPU	3rd Gen Intel? Xeon? Scalable processors Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Core	Up to 40 cores

System Memory
Memory Capacity	32 DIMM slots Up to 8TB Intel? Optane? Persistent Memory 200 Series, DDR4-3200MHz Up to 8TB 3DS ECC LRDIMM, DDR4-3200MHz; Up to 8TB 3DS ECC RDIMM, DDR4-3200MHz
Memory Type	ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
DIMM Sizes	LRDIMM: 16GB, 32GB, 64GB, 128GB, 256GB RDIMM: 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage	1.2V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)

On-Board Devices
Chipset	Intel? C621A
SATA	Intel? C621A controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
IPMI	ASPEED AST2600 BMC
Graphics	1 ASPEED AST2600 BMC port(s)
Network Controllers	N/A

Input / Output

LAN
