超微主板 X12SPG-NF 支持第三代至强 LA4189

超微主板 X12SPG-NF 支持第三代至强 LA4189

Key Features

3rd Gen Intel? Xeon? Scalable processors, Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP
Intel? C621A

Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 2TB Intel? Optane? Persistent Memory 200 Series, in 8 DIMM slots

3 PCIe 4.0 x16 Proprietary Slots
2 PCIe 4.0 NVMe x4
M.2 Interface: 2 SATA/PCIe 3.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Key
1 PCIe 4.0 x8 AIOM

Single LAN with Realtek RTL8211F PHY
(dedicated IPMI)

Intel? C621A controller for 2 SATA3 (6
Gbps) ports; RAID 0,1

Product SKUs
MBD-X12SPG-NF

Physical Stats
Form Factor	Proprietary
Dimension	9.6" x 14.5" (24.38cm x 36.83cm)

Processor
CPU	3rd Gen Intel? Xeon? Scalable processors Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP
Core	Up to 40 cores

System Memory
Memory Capacity	8 DIMM slots Up to 2TB Intel? Optane? Persistent Memory 200 Series Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz; Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz
Memory Type	3200/2933/2666 MT/s ECC , DDR4 LRDIMM (3DS), RDIMM (3DS)
DIMM Sizes	8GB, 16GB, 32GB, 64GB, 128GB, 256GB LRDIMM: 64GB, 128GB RDIMM: 8GB, 16GB, 32GB, 64GB
Memory Voltage	1.2V
Error Detection	Corrects single-bit errors

On-Board Devices
Chipset	Intel? C621A
SATA	Intel? C621A controller for 2 SATA3 (6 Gbps) ports; RAID 0,1
IPMI	ASPEED AST2500 BMC
Graphics	1 ASPEED AST2500 BMC port(s)
Network Controllers	Single LAN with Realtek RTL8211F PHY (dedicated IPMI)

Input / Output
