Key Features1.Single AMD EPYC 7003/7002 Series Processor
(The latest AMD EPYC 7003 Series Processor with AMD 3D V-Cache? Technology requires BIOS version 2.3 or newer)2.2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs3.Expansion slots:
1 PCI-E 4.0 x16 Left Riser Slot
1 PCI-E 4.0 x16 Right Riser Slot
1 PCI-E 4.0 x16 SIOM LAN Networking Slot
M.2 Interface: 4 SATA/PCI-E 4.0 x4
M.2 Form Factor: 22110, 2280, 2260, 2242
M.2 Key: M-key
4.6 SATA3, 4 M.2, 2 SuperDOM5.Onboard LAN Provided by Realtek RTL8211F PHY6.ASPEED AST2500 BMC graphics7.Up to 2 USB 3.0 ports (Rear)
1 USB 2.0 port (Type A)8.2x 4-pin PWM Fans & Speed control
|
|
|
|
| Memory Capacity | |
| Memory Type | |
| DIMM Sizes | 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
|
| Memory Voltage | |
| Error Detection | |
