超微 X11SCQ 支持LGA1151 酷睿10-11代

超微 X11SCQ 支持LGA1151 酷睿10-11代


Key Features

  1. 8th/9th Generation Intel? Core? i9/Core? i7/Core?i5/Core?i3/Pentium?/Celeron? Processor
    Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP

  2. Intel? Q370

  3. Single LAN with Intel? Ethernet Controller I210-AT
    Single LAN with Intel? PHY I219LM LAN controller

  4. Up to 64GB Unbuffered non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

  5. 1 PCIe 3.0 x16,
    1 PCIe 3.0 x1,
    2 PCIe 3.0 x4
    M.2 Interface: 1 PCIe 3.0 x4
    M.2 Form Factor: 2242/2280/22110
    M.2 Key: M-Key

  6. Intel? Q370 controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10

  7. 1 DVI - D port, 1 HDMI port, 1 DP (DisplayPort) port, 1 eDP (Embedded DisplayPort) port,
    3 Independent Displays

Product SKUs
MBD-X11SCQ
Physical Stats
Form Factor

  • uATX

Dimension

  • 9.6" x 9.6" (24.38cm x 24.38cm)

Processor
CPU

  • 8th/9th Generation Intel? Core? i9/Core? i7/Core? i5/Core? i3/Pentium?/Celeron? Processor

  • Single Socket LGA-1151 (Socket H4) supported, CPU TDP supports Up to 95W TDP

System Memory
Memory Capacity

  • 4 DIMM slots

  • Up to 64GB Unbuffered non-ECC UDIMM, DDR4-2666MHz

Memory Type

  • 2666/2400/2133/1866/1600 MT/s SDRAM 72-bit, 288-pin

DIMM Sizes

  • 4GB, 8GB, 16GB

Memory Voltage

  • 1.2V

On-Board Devices
Chipset

  • Intel? Q370

SATA

  • Intel? Q370 controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10

Audio

  • 7.1 HD Audio

Graphics

  • 1 Intel? HD Graphics port(s)

Network Controllers

  • Single LAN with Intel? PHY I219LM LAN controller

  • Single LAN with Intel? Ethernet Controller I210-AT

Input / Output
LAN

  • 2 RJ45 Gigabit Ethernet LAN ports

USB

  • 6 USB 2.0 port(s) (4 via header; 2 rear)

  • 10 USB 3.2 Gen2 port(s) (2 via header; 2 rear type A; 4 rear; 2 rear type C)
