Key Features
13th/12th Generation Intel? Core? i9/i7/i5/i3/Pentium/Celeron Processor,
Single Socket LGA-1700 supported, CPU TDP supports Up to 125W TDP
Intel? R680E
Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR5-4400MHz, in 4 DIMM slots
1 PCIe 5.0 x16 slot,
2 PCIe 4.0 x4 slots,
1 PCIe 4.0 x4 OCulink port
M.2 Interface: 1 PCIe 4.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Key
Dual 2.5 Gigabit LAN with Intel? Ethernet i225LM LAN controller [AMT/vPro]
Intel? R680E Controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
4 Independent Displays (1 VGA port, 2 DP++ ports, 1 HDMI 2.0b port, 1 DVI - D port)
Supports 12V DC power input
Onboard TPM2.0
|
| Memory Capacity | 4 DIMM slots Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR5-4400MHz
*Supports up to 128GB of DDR5 UDIMM with speeds of up to 4400MT/s with one DIMM, or 4000MT/s with two DIMM single rank, or 3600MT/s with two DIMM dual rank in four memory slots
|
| Memory Type | |
| DIMM Sizes | |
| Memory Voltage | |
| Error Detection | |
